X-Rite i1 Publish Pro 3 Plus

Description

Color Management for Imaging and Prepress

For designers, photographers, or prepress professionals who rely on accurate color throughout a digital workflow, the i1Publish Pro 3 Plus is the must-have solution to profile and calibrate cameras, monitors, projectors, scanners, and both RGB and CMYK+ printers. Get the most color accurate displays, prints and proofs, with repeatable results every time.

In addition, the i1Publish Pro 3 Plus is equipped with transmissive profiling capabilities for faster measurements and more accurate and consistent profiles to reduce expensive waste and rework.

Benefits:

• A large aperture (8mm) gives more accurate results with better repeatability.
• Includes a polarizing filter for improved profiles from textiles and other textured media.
• Accommodating a broad range of proficiencies and expertise, i1Publish Pro 3 Plus provides complete power and control to create the highest quality ICC profiles.
• Benefit from perfect printed colors every time with RGB, CMYK, and CMYK + any 4 with intelligent iterative profiling technology for best quality results and advanced controls for black generation and separations.
• Achieve true colors on all modern laptop and desktop display technologies, such as LED, Plasma, RG Phosphor, OLED, and Wide Gamut.
• Quickly check color output quality with the ColorChecker Proof visual assessment target, included with i1Publish.
• Correct for OBAs in paper with Optical Brightener Correction technology (when combined with i1iSis 2 automated chart reader).

Specifications:

•          Aperture Measurement aperture: 8 mm (0.31”) diameter (effective measurement aperture during scanning is depending on the patch                size and measurement speed)
•          Available Disk Space        2GB
•          Calibration          Manual on external ceramic white reference (included)
•          Communication Interface              USB 1.1
•          Connectivity       Powered USB port
•          Dimensions (length, width, height)           i1Pro device: 162 mm x 69 mm x 64 mm (6.4” x 2.7” x 2.5”)
•          Display Resolution           1024×768 pixels or higher
•          Experience Level               Intermediate to Advanced
•          Humidity              30 to 85% RH (non-condensing)
•          Illumination Spot Size     12 mm (0.47”)
•          Inter-Instrument Agreement       0.3 ∆E00* average, 0.8 ∆E00* max. (deviation from X-Rite manufacturing standard at a temperature             of 23ºC (73.4ºF) on 12 BCRA tiles (D50, 2º))
•          Internet Connection        Required for software install, download and automatic update
•          Languages Supported     Chinese (Simplified), English, French, German, Italian, Japanese, Korean, Portuguese, Spanish
•          Light Source        i1Pro3 Plus LED Illumination (including UV)
•          Macintosh           MacOS X 10.11x, 10.12x or 10.13x (with latest upgrades installed)
•          Measurement Conditions:


  o   M0 – UV included – ISO 13655:2017
  o   M1 – D50 – ISO 13655:2017
  o   M2 – UV excluded Filter – ISO 13655:2017
  o   M3 – Polarization – ISO 13655:2017

•          Measurement Frequency in Scanning Mode         400 measurements per second
•          Measurement Geometry               45°:0° ring illumination optics, ISO 13655:2017
•          Measurement Spot          8mm (0.315”)
•          Media Thickness               1mm or less
•          Memory               2GB Minimum
•          Number of Displays Supported per Workstation Up to 4
•          Operating Temperature Range    10°C to 35°C
•          50°F to 95°F
•          Patch Size            Minimal Patch Size in Scanning Mode: 16 x 16 mm (0.63” x 0.63”) (Width x Height) with sensor ruler 20 x 16 mm                   (0.79” x 0.63”) (Width x Height) without sensor ruler
•          Photometric Range          10nm; Sampling interval 3.5nm
•          Processor            MAC: Intel® Core 2 Duo CPU or better; WINDOWS: Intel® Core 2 Duo or AMD Athlon™ XP or better
•          Scan Length        Maximum 515mm (20.28″)
•          Scanner Target Support Yes
•          Scanning Capability         Yes
•          Security                User must have Administrator rights to install and uninstall the application
•          Short Term Repeatability – White               0.05 ∆E00  on white (D50,2°, mean of 10 measurements every 3 seconds on white)5
•          Software Development Kit            Available for OEM customers
•          Spectral Analyzer              i1® technology with built-in wavelengths check; Holographic diffraction grating with 128-pixel diode array
•          Spectral Range   380 – 730 nm
•          Spectral Reporting           380 … 730 nm in 10 nm steps
•          Storage Temperature Range         -20° to 50°C
•          -4° to 122°F
•          Supported Profile Format             ICC version 2, version 4.3,  & iccMax
•          Unit Color            Black/Silver
•          User Experience                Choose between a ‘basic’, wizard-driven interface or an ‘advanced’, user-driven interface for highest level                     professional results
•          Video Card
•          MAC: Latest drivers for video card installed
•          WINDOWS: Latest drivers for video card installed, dual display support requires either 2 video cards or a dual head video card that                    supports dual video LUTs being loaded
•          Warranty             Twelve (12) months from the date of sale, unless different local regulations apply. Product registration is required to               receive X-Rite technical support during the warranty period. Registration can occur directly through the software, on our website, or via phone. Users are encouraged to register their product within the first 30 days of use.
•          Weight  i1Pro device: 285 g (10.1 oz)
•          What’s Included?             i1Pro 3 Plus spectrophotometer (measurement device), calibration plate, polarizing filter, ambient light measurement head, monitor holder, positioning target, XL scanning ruler, XL backer board, USB cable.  i1Profiler v3.x software for monitor profiling plus QA for monitors and printers.
•          Windows             Windows 7, 8, 8.1, 10 (with latest Service Pack installed)
